Nick from Metal Head Fabrication finally got his boardtracker xs650 bike wrapped up. We posted this bike up on the web  just a few months back. This bike got a lot of comments and questions, so we brought you a stack of pictures of the finished ride for you to drool over.

wall tracker 2
wall tracker 1
wall tracker 3
wall tracker 15

Comments from the earlier post: reynoldburton said: Oh, thats something completely different. Much respect to this boardtrackerstyle masterpiece! Never seen something like this before done to an XS – turned out really nice.

-Nick- The tanks are aluminum, which really isn’t my prefered material. I’m more of a steel person myself. Each one is made of two halves that were hammer formed and then welded together. It took a healthy mix of files, flap wheels, and fiber pads to get them smoothed out. Putting the hours in to get them together started to seem like a hassle about half way through, but seeing them on there made me forget about the labor, sort of.

wall tracker 9
wall tracker 10

Comments from the earlier post: WannaXS said: Cool looking machine. I think thats the first XS I have seen with a leaf fork thingy..

-Nick- The forks were a fun project. The spring is a trailer leaf that’s been cut in half. Having a custom spring made or getting a replica Indian spring could be an option, but they can be pretty pricey. Aside from being more affordable, I kind of like the shape of the average leaf spring more than the flat ones. Plus, making good use of parts intended for something else just adds to that feel of chopping!

wall tracker 6
wall tracker 8

-Nick- My favorite part on the bike is probably the rear fender. A while back a friend actually made his own fender rolling machine to make a single fender for his own bike. The idea of having one done in solid brass popped in my head, so I ran it by him. Straight away he was into it. He wouldn’t take money for it and only made me buy the material. The quality of the fender blew my mind. That and the fact that it was basically a gift really made it a cool part to be able to add to the bike.

wall tracker 11
wall tracker 22
wall tracker 20
wall tracker 18
wall tracker 19

-Nick- There’s plenty of spots on the bike that could be added on to, but it’s been too nice out lately. It felt like it was time to take it out for some summer time rides.
