noid-chopperwiringdiagram

Click to large/download

I got tired of looking for a good diagram for the Yamaha xs650 that wasn’t completely wrong….so i made one.  simple, easy to read and to the point.  hope it came out as clear as i looks to me.

A couple of key notes: The brush assembly of the stator must be ungrounded. This means taking the 3 screws attaching the brushes to the outside of the stator and replacing with 4MMx.1 nylon screws 11MM long, no plastic. I couldn’t find any in town so I got some 8MM nylon round stock, ground it down and used a die for the threads.

You can find them at smallparts.com Just search 4MM nylon screw. Note #2 if your backfiring through your carbs, switch the orange and grey wires coming off the points. The orientation of the wire colors depends on the last person to change the points.

noid-stator_screw

Thanks wayward wayne
